Series image: for reference only

Rated Current: 0.375A-10A
Rated Voltage: (0.375A-0.75A):125V (1A-10A):63V
Melting characteristic: Fast Acting
Breaking Capacity: V =63V DC ; I=50A
Safety Approval: UL:E56092
View Product Specification
Company Profile: Walter 英文简介2020.pdf
Data Sheet: Walter_1206F.pdf
RoHs Report: ChiPCSRFuse系列ROHS A222011430810400101R1.pdf
Electronic: Walter_ Product_overview.pdf
REACH Report: WALTER_SMD_FUSE_REACH233.pdf
Export Page to PDF
Specification

Series Introduce

Attribute Name Attribute Value
Rated Current 0.375A-10A
Rated Voltage (0.375A-0.75A):125V (1A-10A):63V
Melting characteristic Fast Acting
Size 1206(3.2mm*1.6mm)
Substrate Alumina Ceramic
Adhesion layer Epoxy
Fuse element Cu Alloy / Sn
Terminal electrode Cu / Ni / Sn
Protective coating Flame-retardant epoxy
Marking coating Flame-retardant epoxy
Safety Approval UL:E56092
Operating Temperature -55℃~150℃
Storage Conditions 10℃~40℃
Solder pad size and welding conditions
Preheating 145 ± 15℃, max. 120 sec
Soldering min. 220℃, max. 60 sec.
Maximum temperature 260±5℃, max. 10sec.
Rework Temperature (hot air equipment) 350℃,3~5seconds
Breaking Capacity V =63V DC ; I=50A
Safety Approval UL:E56092
